UniFi IDS/IPS

UniFi Gateway uses the Suricata rules engine

IDS does not use iptables, uses live pcap on a Unix socket

IPS adds chains to the forward chain

Chain FORWARD (policy ACCEPT)
target     prot opt source               destination
TOR        all  --  anywhere             anywhere
ALIEN      all  --  anywhere             anywhere
IPS        all  --  anywhere             anywhere

IPS Rule

Chain IPS (1 references)
target     prot opt source               destination
IPSLOGNDROP  all  --  anywhere             anywhere             match-set ips dst,dst (Port),src
IPSLOGNDROP  all  --  anywhere             anywhere             match-set ips src,src (Port),dst

Rules are stored in *.rules files in the directory /usr/share/ubios-udapi-server/ips/rules/

category_list.json In the config folder, there is an array called open that lists the free rules, and there is also an array called pro that contains the rules that require a CyberSecure subscription

Rules come from EmergingThreats, maintained by Proofpoint.

IP Reputation

• Malicious Hosts adds the ALIEN chains to iptables
• Dark Web Block List adds the TOR chains to iptables

Notify Only (IDS) will also drop if these detections are enabled

Chain ALIEN (2 references)
target     prot opt source               destination
ALIENLOGNDROP  all  --  anywhere             anywhere             match-set ALIEN src

Chain ALIENLOGNDROP (1 references)
target     prot opt source               destination
RETURN     all  --  anywhere             anywhere             match-set ALIEN_WHITELIST_SRC src
RETURN     all  --  anywhere             anywhere             match-set ALIEN_WHITELIST_DST dst
NFLOG      all  --  anywhere             anywhere             limit: avg 1/min burst 5 nflog-prefix  "[IGNORE LOGGING]" nflog-group 3 nflog-threshold 16
DROP       all  --  anywhere             anywhere

alien.list and tor.list containing the IP address to drop are in the /usr/share/ubios-udapi-server/ips/rules/ directory

Logs of dropped connections containing interfaces, MAC Addresses, and IP Addresses are stored in /var/log/ulog/alien_block.log and /var/log/ulog/tor_block.log
