Port Security

Defends against CAM table overflow attacks.

Can be configured on both Access or Trunk ports, but not a Dynamic port.

Can set the maximum MAC per VLAN on a trunk port.

Violation Actions

• Protect: It drops the packets with an unknown source address. It does so until you delete a sufficient number of secure MAC addresses. No logs or alerts.
• Restrict: It drops the packets with unknown source addresses until you get rid of a sufficient number of secure MAC addresses to drop below the maximum value. It causes the SecurityViolation counter to increase and generates logs and alerts.
• Shutdown: It causes the interface to enter an error-disabled state immediately. It then sends an SNMP trap notification. Default action.
• Shutdown VLAN: shuts down the entire VLAN.

Dynamic: MAC addresses are learned.

Static: MAC addresses are manually configured on the switch port

Sticky: MAC addresses are learned and put in the running config.

Port Configuration

int gi 1/0/1
  switchport mode access
  switchport access vlan 123
  switchport port-security maximum 2
  switchport port-security aging type inactivity
  switchport port-security aging time 5
  switchport port-security violation restrict
  switchport port-security mac-address 0000.0000.0000
  switchport port-security mac-address sticky
  switchport port-security

Verification commands

show port-security addresses
show port-security
show port-security int gi1/0/1

Automatic Recovery

Default is 300 seconds

errdisable recovery cause psecure-violation
errdisable recovery interval 300
