PIX - Access Control Lists

• Security Levels set the default permissions
• Interface ACL denies or permits initial inbound packet on the interface
• With higher to lower security levels use ACLs to restrict access
• ACLs are always processed before PIX does any translations
• Outbound packet source address is the untranslated address of the host
• Inbound packets source address is the translated global IP address

To permit inbound traffic to a web server

1. Static translation to web server
2. Inbound ACL to grant access
3. Apply ACL to the interface

static (dmz,outsite) 192.168.0.19 172.16.0.12 0 0

access-list outsidelist permit tcp any host 192.168.0.19 eq www

access-group outsidelist in interface outside

show access-list

Static translation (Inside interface, Outside interface) translated address host address

ACL Log Generation

Add log to the access control entry to generate a syslog

Interval causes the hit count to reset

access-list outsidelist permit icmp any host 192.168.1.1 log 7 interval 500

memory-intensive

• For ACLs with 19 or more access control entries
• Improves the search by generating compile tables
• Can be enabled globally or for certain ACLs
• Turbo ACL’s are not supported on PIX 501, typically used on PIX 525 or 535
• Very memory-intensive, minimum 2.1 MB required

!! All access lists with more than 19 entries
access-list compiled

!! Specific access list
access-list mylist compiled

NAT Zero

Exempt VPN traffic from being translated

access-list NO_NAT_VPN permit ip 10.0.0.0 255.255.255.0 10.200.0.0 255.255.255.0

nat (inside) 0 access-list NO_NAT_VPN
