CoPP - Control Plane Policing

Cisco Dec 30, 2024

Control Plane Functions:

  • Builds the routing and forwarding tables for the data planes
  • Runs on the process level
  • Shares the main CPU with the slow data path processes and management processes
  • By default, it also shares the path (queue) to the main CPU

Threats:

  • Slow path denial-of-service attacks
  • Routing protocol spoofing

CoPP:

  • Permits or denies access to the control plane
  • Rate-limits access to the control plane
  • Configured as a service policy on a virtual control plane interface

ACLs to identify the traffic flows seen by the control plane

ip access-listed extended ICMP-CoPP
	permit icmp any any echo-reply
	permit icmp any any echo

ip access-listed extended IPSec-CoPP
	permit udp any eq isakmp any eq isakmp
	permit esp any any
	permit gre any any

ip access-listed extended Mgmt-CoPP
	permit tcp any any eq www
	permit tcp any any eq 443
	permit tcp any any eq telnet
	permit tcp any any eq 22
	permit udp any any eq snmp

ip access-listed extended Routing-CoPP
	permit tcp any eq bgp any established
	permit eigrp any host 224.0.0.10
	permit ospf any host 224.0.0.5
	permit ospf any host 224.0.0.6

Match the ACLs to class maps

class-map match-all ICMP-CoPP-MAP
	match access-group name ICMP-CoPP

class-map match-all IPSec-CoPP-MAP
	match access-group name IPSec-CoPP

class-map match-all Mgmt-CoPP-MAP
	match access-group name Mgmt-CoPP

class-map match-all Routing-CoPP-MAP
	match access-group name Routing-CoPP

Define a policy map to police traffic classes

policy-map CoPP-POLICY
	class ICMP-CoPP-MAP
		police 8000 confirm-action transmit exceed-action drop
	class IPSec-CoPP-MAP
		police 64000 confirm-action transmit exceed-action drop
	class Mgmt-CoPP-MAP
		police 64000 confirm-action transmit exceed-action drop
	class Routing-CoPP-MAP
		police 128000 confirm-action transmit exceed-action drop
	class class-default
		police 8000 confirm-action transmit exceed-action drop

Apply the policy map to the control plane as a service policy

control-plane
	service-policy input CoPP-POLICY

CoPP Verification

show policy-map control-plane
